Night Vision Dome Camera
Key Features & Benefits
-
AHD 720P / 1080P video (optional)
Higher definition image compared with traditional CVBS analog cameras, compatible with AHD monitors and MDVRs. -
Strong night vision performance
Equipped with 24 infrared LEDs, minimum illumination 0 Lux (IR on) with an effective night vision range of approximately 5 meters. -
120° wide viewing angle
Covers a broad area around the vehicle to reduce blind spots when reversing or monitoring side / interior areas. -
IP69K waterproof & dustproof
Fully sealed housing withstands high-pressure, high-temperature wash-downs and severe weather conditions. -
10G anti-vibration design
Specially designed for commercial vehicles, resisting shock and vibration on rough roads. -
Compact dome housing
Low-profile design is easy to install on ceilings or walls inside cabins, trailers, bus interiors or vehicle exteriors. -
Wide operating temperature
Works reliably from -20°C to +70°C, storage from -30°C to +80°C, suitable for both hot and cold climates.
Technical Specifications
- With night vision 24PCS LED lights,aseismatic
- Pixel:PAL: 976*582; NTSC: 976*494
- Arrange:120°
- Waterproof Grade: IP69K
- Video output:1.0Vp-p,75Ω
- Grade of shockproof: 10G
- Focal length: F=2.9mm
- The lowest lux: 0 ( 24 pcs LED open, the distance of night vision is 5m.)
- Power: DC12V
- Operating Temperature: -20°C ~ +70°C
- Storage Temperature: -30°C~+80°C
Typical Applications
-
Interior or exterior monitoring on trucks, vans and trailers
-
Bus passenger area and doors
-
Forklifts and construction machines for work-zone monitoring
-
Agricultural and mining equipment operating in dusty, wet environments
-
Any application requiring a compact IP69K night vision dome camera
