AHD 10.1 inch IP69K Waterproof Quad Monitor: Enhance Your Visibility and Safety
The AHD 10.1-inch IP69K Quad Monitor combines large-format visibility with industrial durability. Supporting AHD 720P/1080P cameras (CVBS backward compatible), it displays up to four views simultaneously to eliminate blind spots around heavy vehicles. With IP69K waterproof housing, high-brightness panel, and 12–36V power, it’s the dependable choice for fleets operating in rain, dust and vibration.
This system is ideal for operators who require comprehensive visibility around large vehicles, especially in off-road or outdoor conditions. Supporting AHD 720P/960P/1080P video signals, it provides crisp and real-time imaging for parking assistance, blind spot elimination, and multi-angle monitoring.
Key Features
-
Large 10.1-Inch LCD Display
High-resolution screen with superior brightness and clarity for outdoor and in-cab use. -
IP69K Waterproof Design
Rated for extreme weather, pressure washing, and dusty or muddy environments. -
Quad Camera Input
Supports up to 4 cameras simultaneously with split-screen, dual, triple, or full-screen viewing modes. -
Flexible Video Formats
Compatible with AHD, CVBS, and hybrid signal inputs (720P, 960P, 1080P @ 25/30fps). -
Trigger Support & Parking Guidelines
Built-in reverse triggers, auto-switching, parking grid lines, and boot memory function. -
Multiple Mounting Options
Includes robust metal U-type bracket and optional suction mount for flexible installation. -
Anti-Glare Sunshade
Included detachable sun visor enhances screen visibility in sunlight.
⚙️ Technical Specifications
| Feature | Detail |
|---|---|
| Screen Size | 10.1 inch TFT LCD |
| Resolution | 1024 × 600 |
| Brightness | ≥ 400 cd/m² |
| Contrast Ratio | 500:1 |
| Color | Black |
| Video Inputs | 4 Channels (AHD/CVBS/Hybrid) |
| Power Supply | DC 12V–36V |
| Operating Temp | -20°C to +70°C |
| Storage Temp | -20°C to +80°C |
| IP Rating | IP69K Waterproof |
| Mounting | Metal U bracket + optional suction base |
