12.3-Inch HD IPS Screen Electronic Smart Mirror

Dual 1080P AHD Camera Inputs
Supports real-time split-view monitoring with two high-definition camera channels.
Wide IPS Display
Crystal-clear 12.3-inch IPS screen with 850 cd/m² brightness and 800:1 contrast ratio ensures sharp visuals in all lighting conditions.
Fast 3-Second Boot-Up
Minimizes wait time and starts instantly when powered on.
Advanced Recording Capabilities
Supports up to 256GB TF card for continuous video recording.
Flexible Power Input
Operates on 9V–36V DC systems, suitable for various commercial vehicles.
Strong Night Vision Performance
Equipped with 6 IR LEDs per camera to capture details even in complete darkness.
Durable Waterproof Cameras
IP68-rated cameras ensure long-lasting use in outdoor and industrial environments.
Wide-Angle View
Horizontal: 150°, Diagonal: 170° field of vision reduces blind spots and improves awareness.

Send Inquiry

Category: Mirror Monitor

Description

12.3-Inch HD IPS Smart Mirror – The Future of Vehicle Safety

Upgrade your vehicle with the latest in smart monitoring technology. The 12.3-Inch HD IPS Smart Mirror combines the functions of a rearview mirror, DVR, and high-definition split-screen monitor into one compact and intelligent device. It’s designed for trucks, forklifts, buses, and commercial vehicles seeking improved safety, visibility, and operational convenience.

📋 Technical Specifications

Item	Details
Screen Size	12.3-inch IPS
Brightness	850 cd/m²
Contrast Ratio	800:01:00
Video Input	AHD 1080P/960P/720P, CVBS/960H
Recording Storage	TF card (Max 256GB)
Boot Time	≤3 seconds
Power Supply	DC 9V–36V
Video Format	PAL/NTSC auto switch
Camera Waterproof Rating	IP68
Night Vision	6 IR LEDs per camera
Viewing Angle	150° horizontal, 170° diagonal
Housing Material	Metal / Plastic
Connector	4-pin aviation connector
